WE-GW-B210
HonorInsight IoT/ OEM
8537109090
Shenzhen, China
50000PCS/Year
T/T
3 years
| Protection grade: | |
|---|---|
| Quantity: | |
| PDF Export | |
2.4GHz Gateway
(WE-GW-B210)
1.Introduction
The 2.4G outdoor gateway is an industrial-grade IoT mesh gateway. Combined with the 2.4G mesh lighting controller developed by our company, it can realize intelligent lighting control. The products can be flexibly applied to various scenarios, such as street lighting, industrial factory lighting, tunnel lighting, stadium lighting, etc. The gateway supports ETH Ethernet, 4G wireless communication networking, node data collection, support for multiple protocol conversion, data forwarding, virtual private network, local data storage and other functions in one. It is widely used in smart lighting, road lighting, industrial lighting, smart agriculture and smart photovoltaic industries.
2. Features
It integrates functions such as data collection, multiple protocol conversion, IoT gateway, data processing and forwarding, virtual private network, local storage, etc.;
The HonorInsight IoT M2M device cloud platform can centrally monitor, configure, upgrade, and diagnose a large number of communication terminals distributed in various places, greatly reducing the maintenance costs of operators, integrators, equipment providers, etc., and improving management efficiency ;
Based on the secondary development of Linux, customers can carry out secondary development of upper-layer applications according to project requirements, and the standard is easy to use;
Full Netcom/4G wireless communication;
AC wide voltage input, AC110V-AC265V, 10KV lightning protection level; full network coverage, options include full Netcom/4G/3G, comprehensive coverage of domestic and overseas operator networks, more flexible project application;
Configuration parameters can be saved, which greatly improves the configuration efficiency of a large number of M2M devices, and supports parameter backup and import;
ETH Ethernet communication, 10M/100M adaptive;
Support TCP/IP, MQTT, HTTP, QoS, WMM, WMM-PS and other protocols
3. Parameters
Interface | Name | Specification | Remark |
Interface | SIM card plot | 1 | Support 1.8V/3V SIM/UIM card Built-in 10KV ESD protection |
Indicator | Indicator | 1 | Red is the power-on state, blue is connected to the network, and green is connected to the network successfully |
Interactive | Antenna interface | 2 | Interface form: SMA interface Interface allocation: WIFI antenna x1 2.4G antenna x1 |
CPU | Edge computing | CPU | 32-bit processor |
CPU | Edge computing | DDR | 128MB DDR Scalable to 256MB |
CPU | Edge computing | FLASH | 32M FLASH Scalable to 128MB |
CPU | AI core | CPU | MIPS24KEc, super data processing capability, MCU main frequency up to 580MHz |
Operation and maintenance | Safety | Link detection | PPP layer heartbeat ICMP detection Multi-level link detection mechanisms such as TCP and application layer heartbeat to maintain wireless links And support automatic reconnection after disconnection Ensure that the equipment is "always online" to support equipment operation self-check technology |
Operation and maintenance | Safety | Built-in watchdog | Support equipment operation self-check technology Support equipment self-recovery from operation failure Hardware watchdog Software watchdog |
Operation and maintenance | Network management | Network management | Support automatic dialing when the device is powered on Support long connection mode, short connection mode Support Cloud Voice M2M device cloud platform, remote configuration Use local serial port or remote way for software upgrade Support local or remote viewing of output logs, which is convenient for engineers to view the operating status of equipment Support Cloud Voice M2M device cloud platform, remote centralized management of communication terminals distributed in various places |
Industrial design | Protection level | IP65 | Metal shell System security isolation Profile heat dissipation |
Industrial design | Applicable environment | Physical structure | Range of working temperature: Minus 40ºC～85ºC Storage temperature range: Minus 45ºC～90ºC Relative humidity range: 15~95%RH non-condensing |
Industrial design | Physical structure | Physical structure | Installation method: Wall-mounted Dimensions: 150x128x60MM |
Supply voltage | Power Supply | - | AC: 110V-265V |
4. Size(Unit:MM)
