WE-MA-B10
HonorInsight IoT/ OEM
8537109090
Shenzhen, China
5000000PCS/Year
T/T
3 years
| Size: | |
|---|---|
| Color: | |
| protocol: | |
| protection grade: | |
| Quantity: | |
| PDF Export | |
2.4GHz IoT Light Controller
1. Introduction
WE-CON-B10 is a 2.4GHz MESH single light controller with power grid parameter measurement and statistical functions. Combined with our self-developed cloud platform and mobile APP, it can realize intelligent control of lights. The controller has power grid parameter acquisition, relay output, 0-10v (PWM) output, and has the functions of manual control, automatic control, strategy control and fault alarm of lights. This series of products is specially designed for industrial lighting scenes, street lights, high bay lights, high pole lights, plant lighting, landscape lighting and other applications. Ultra-high efficiency, compact shell design, and good heat dissipation greatly improve the reliability of the product and prolong the life of the product. All-round protection, including lightning protection, over-voltage protection, short-circuit protection and over-temperature protection, ensures the trouble-free operation of this product.
2. Features:
Application Design
Compact shell design, with excellent thermal performance and waterproof performance
Grid parameter collection
Energy consumption statistics
Policy control
Fault and status reporting function
Remote firmware upgrade
Multiple Support
2.4G MESH wireless communication
Support local one-to-one upgrading via mobile phone
Support local modification of server address and port information
Support local detection of light controller signal strength, device time and network connection status
Support local detection device ID, ICCID, metering module status, RTC module status
Support local reading of light control system information, parameter information, policy information, inspection time, device chip status
Support remotely or locally control the brightness of the light via mobile phone
Support local reading of lamp controller voltage and current data
Support 0-10V dimming, support PWM dimming
Lightning protection: differential mode 6KV, common mode 6KV
All-round protection: over-temperature protection, over-voltage protection, leakage protection
IP65 and suitable for UL dry, humid and watery environment
3 years warranty
3. Parameters
parameter | Specification | Remarks |
Input voltage | AC85V-265V | Wide voltage input, 220V by default |
The output voltage | AC85V-265V | Wide voltage output |
Rated output current | 5.2A | Large load needs to be customized |
Rated output power | 1000W | 220V typical input |
Number of output | 1 way | Optional two outputs |
Dimming method | 0-l0 V or PWM | The default is 0-10V |
Dimming range | 0-100% | Need driver support |
Grid parameters | Voltage, current, power factor, power | Statistics can be calculated |
Protection level | IP65 | - |
Installation size | 130L*70W*40H(MM) | - |
Antenna | Glue stick or magnetic antenna | - |
Hardware parameters | Specification |
Power metering | 0-100% brightness full range power metering |
Measurement error | ≤±2% |
Maximum driveable load current | ≤10A per group |
Control strategy data storage time limit | can support continuous power failure for 168 hours without loss of strategy data |
Working temperature | -40℃~+80℃ |
Adapt to humidity | ≤95% |
EMC test complies with the following standards | GB/T9254.1-2021, GB/T9254.2-2021 |
Lightning protection | common mode 6KV, differential mode 6KV |
Leakage measurement | The minimum measurable leakage current is 5mA |
Lightning protection grounding wire monitoring | The hardware can upload the grounding condition of the equipment |
Communication method | 2.4G mesh wireless networking to issue control commands and strategies, and report data, and remote firmware upgrades, support offline mobile phone local control devices, check device operation |
4. Wiring definition
Controller Input | Controller Output 1 | Controller Dimming |
L line: Bronze N line: Blue GND line: Yellow green | L line: Bronze N line: Blue GND line: Yellow green | Dim+ line: Purple Dim- line: Grey |
5. FAQ:
Q1: Do you provide sample for test?
A1: Yes. Please feel free to make a sample order.
Q2: What is the MOQ.
A2: Please send your inquiry. We will provide the Latest Price and MOQ.
Q3: What is your payment?
A3: We accept T/T, Paypal etc.
Q4: What is your deliver time?
A4: Usually, 7-15 days for sample order, 20-30 days for batch order.
Q5: What about your shipment?
A5: We use DHL, EMS etc for sample order, for batch order, by sea or by air.
Q6: How many Lighting controllers can one gateway control?
A6: Around 500 controllers.
Q7: Can lighting controllers working when the gateway not working?
A7: Yes. Controller will keep working as strategy.
